SecureAir Female Threaded Valve (FV) is a robust ball valve designed for controlling airflow in compressed air systems. Featuring a female thread connection, it integrates seamlessly with existing setups, offering reliable shut-off and regulation. Crafted from anodized aluminum with SS304 hardware, it supports up to 16 bar pressure and comes with a 15-year warranty. 100% Made in India, compliant with ISO, BIS, ASTM, and EN standards.
Overview
The FV valve provides a durable solution for on/off control at key points in your piping system. Compatible with various thread standards (NPT/BSP), it ensures leak-proof performance with easy installation and maintenance.
Specifications
| Sr No | Item Code | Sizes | |
| 42.01 | FV12 | 1/2″*1/2″ BSP | Ball |
| 42.11 | FV20 | 3/4″*3/4″ BSP | Ball |
| 42.21 | FV25 | 1″*1″ BSP | Ball |
| 42.25 | FV32 | 1.1/4″*1.1/4″ BSP | Ball |
| 42.31 | FV40 | 1.1/2″*1.1/2″ BSP | Ball |
| 42.41 | FV50 | 2″*2″ BSP | Ball |
| 42.51 | FV63 | 2.1/2″*2.1/2″ BSP | Ball |
| 42.61 | FV80 | 3″*3″ BSP | Ball |
| 42.71 | FV100 | 4″*4″ BSP | Ball |
| 42.81 | FV150 | 6″*6″ BSP | Butterfly |
| 42.91 | FV200 | 8″*8′ BSP | Butterfly |
Note: Dimensions are approximate. Apply torque per specified range using a torque wrench. Thread types (NPT/BSP) available per request.
Benefits
- Precise Control: Ball valve design for reliable on/off operation.
- Leak-Proof Seal: Interlocking technology ensures zero air loss.
- Easy Integration: Female threads match standard fittings.
- Corrosion Resistance: Anodized aluminum withstands harsh conditions.
Technical Details
- Material: Anodized aluminum body, SS304 hardware.
- Pressure Rating: Max 16 bar; Test: 30 bar.
- Temperature Range: -20°C to +80°C.
- Weight: 0.5-5 kg depending on size.
- Installation Notes: Use PTFE tape on threads; tighten per torque specs.
